Alternative Visualization Methods

CostGraph supports other visualization methods such as Grafana and Superset.

​
Superset Access

Superset Credentials
Unless modified, the username and password for the superset instance is admin and admin

​
Access Methods

  • Port forward
  • Ingress
If you do not have ingress set up you can always access superset through a port forward
kubectl port-forward svc/superset  -n costgraph  8080:80

​
Prometheus Metrics

Exposing Prometheus Metrics
You must have service auto-discovery enabled for kubernetes services to have the operator metrics scraped by the prometheus server. If you don’t see costgraph targets, manually add this scrape configuration:
- job_name: 'costgraph'
  honor_labels: true
  scrape_interval: 1m
  scrape_timeout: 10s
  metrics_path: /metrics
  scheme: http
  static_configs:
    - targets: ['costgraph.costgraph:9090']

​
Grafana Dashboard

Install the Grafana dashboard from the costgraph-manifests repository for a familiar Grafana feel.
